Monitoring Spring Boot Application With Micrometer, Prometheus And Grafana Using Custom Metrics

Monitoring Spring Boot Application With Micrometer, Prometheus And Grafana Using Custom Metrics Image

It is important to monitor an application's metrics and health which helps us to improve performance, manage the app in a better way, and notice unoptimized behavior. Monitoring each service is important to be able to maintain a system that consists of many microservices.

In this blog post, I will demonstrate how a Spring Boot web application can be monitored using Micrometer which exposes metrics from our application, Prometheus which stores the metric data, and Grafana to visualize the data in graphs.

Implementing these tools can be done quite easily by adding just a few configurations. Additional to the default JVM metrics I will show how you can expose custom metrics like a user counter.

As always, the code for the demo used in this article can be found on GitHub.

Spring Boot

The base for our demo is a Spring Boot application which we initialize using Spring Initializr:

Spring Initializr

We initialized the project using spring-boot-starter-actuator which already exposes production-ready endpoints.

If we start our application we can see that some endpoints like health and info are already exposed to the /actuator endpoint per default.

Triggering the /actuator/health endpoint gives us a metric if the service is up and running:

bash
1 http GET "http://localhost:8080/actuator/health"
2HTTP/1.1 200
3Connection: keep-alive
4Content-Type: application/vnd.spring-boot.actuator.v3+json
5Date: Wed, 21 Oct 2020 18:11:35 GMT
6Keep-Alive: timeout=60
7Transfer-Encoding: chunked
8
9{
10    "status": "UP"
11}

Spring Boot Actuator can be integrated into Spring Boot Admin which provides a visual admin interface for your application. But this approach is not very popular and has some limitations. Therefore, we use Prometheus instead of Spring Boot Actuator and Grafana instead of Spring Boot Admin to have a more popular and framework/language-independent solution.

This solution approach needs vendor-neutral metrics and Micrometer is a popular tool for this use case.

Micrometer

Micrometer provides a simple facade over the instrumentation clients for the most popular monitoring systems, allowing you to instrument your JVM-based application code without vendor lock-in. Think SLF4J, but for metrics.

Micrometer is an open-source project and provides a metric facade that exposes metric data in a vendor-neutral format that a monitoring system can understand. These monitoring systems are supported:

  • AppOptics
  • Azure Monitor
  • Netflix Atlas
  • CloudWatch
  • Datadog
  • Dynatrace
  • Elastic
  • Ganglia
  • Graphite
  • Humio
  • Influx/Telegraf
  • JMX
  • KairosDB
  • New Relic
  • Prometheus
  • SignalFx
  • Google Stackdriver
  • StatsD
  • Wavefront

Micrometer is not part of the Spring ecosystem and needs to be added as a dependency. In our demo application, this was already done in the Spring Initializr configuration.

Next step is to expose the Prometheus metrics in application.properties:

management.endpoints.web.exposure.include=prometheus,health,info,metric

Now we can trigger this endpoint and see the Prometheus metrics:

See response output
bash
1 http GET "http://localhost:8080/actuator/prometheus"
2HTTP/1.1 200
3Connection: keep-alive
4Content-Length: 8187
5Content-Type: text/plain; version=0.0.4;charset=utf-8
6Date: Thu, 22 Oct 2020 09:19:36 GMT
7Keep-Alive: timeout=60
8
9# HELP tomcat_sessions_rejected_sessions_total
10# TYPE tomcat_sessions_rejected_sessions_total counter
11tomcat_sessions_rejected_sessions_total 0.0
12# HELP system_cpu_usage The "recent cpu usage" for the whole system
13# TYPE system_cpu_usage gauge
14system_cpu_usage 0.0
15# HELP jvm_buffer_count_buffers An estimate of the number of buffers in the pool
16# TYPE jvm_buffer_count_buffers gauge
17jvm_buffer_count_buffers{id="mapped",} 0.0
18jvm_buffer_count_buffers{id="direct",} 3.0
19# HELP jvm_memory_used_bytes The amount of used memory
20# TYPE jvm_memory_used_bytes gauge
21jvm_memory_used_bytes{area="heap",id="G1 Survivor Space",} 1.048576E7
22jvm_memory_used_bytes{area="heap",id="G1 Old Gen",} 3099824.0
23jvm_memory_used_bytes{area="nonheap",id="Metaspace",} 3.9556144E7
24jvm_memory_used_bytes{area="nonheap",id="CodeHeap 'non-nmethods'",} 1206016.0
25jvm_memory_used_bytes{area="heap",id="G1 Eden Space",} 3.3554432E7
26jvm_memory_used_bytes{area="nonheap",id="Compressed Class Space",} 5010096.0
27jvm_memory_used_bytes{area="nonheap",id="CodeHeap 'non-profiled nmethods'",} 6964992.0
28# HELP jvm_gc_pause_seconds Time spent in GC pause
29# TYPE jvm_gc_pause_seconds summary
30jvm_gc_pause_seconds_count{action="end of minor GC",cause="Metadata GC Threshold",} 1.0
31jvm_gc_pause_seconds_sum{action="end of minor GC",cause="Metadata GC Threshold",} 0.009
32# HELP jvm_gc_pause_seconds_max Time spent in GC pause
33# TYPE jvm_gc_pause_seconds_max gauge
34jvm_gc_pause_seconds_max{action="end of minor GC",cause="Metadata GC Threshold",} 0.009
35# HELP jvm_gc_live_data_size_bytes Size of old generation memory pool after a full GC
36# TYPE jvm_gc_live_data_size_bytes gauge
37jvm_gc_live_data_size_bytes 4148400.0
38# HELP jvm_gc_max_data_size_bytes Max size of old generation memory pool
39# TYPE jvm_gc_max_data_size_bytes gauge
40jvm_gc_max_data_size_bytes 4.294967296E9
41# HELP tomcat_sessions_active_current_sessions
42# TYPE tomcat_sessions_active_current_sessions gauge
43tomcat_sessions_active_current_sessions 0.0
44# HELP process_files_open_files The open file descriptor count
45# TYPE process_files_open_files gauge
46process_files_open_files 69.0
47# HELP http_server_requests_seconds
48# TYPE http_server_requests_seconds summary
49http_server_requests_seconds_count{exception="None",method="GET",outcome="SUCCESS",status="200",uri="/actuator/health",} 1.0
50http_server_requests_seconds_sum{exception="None",method="GET",outcome="SUCCESS",status="200",uri="/actuator/health",} 0.041047824
51# HELP http_server_requests_seconds_max
52# TYPE http_server_requests_seconds_max gauge
53http_server_requests_seconds_max{exception="None",method="GET",outcome="SUCCESS",status="200",uri="/actuator/health",} 0.041047824
54# HELP jvm_threads_peak_threads The peak live thread count since the Java virtual machine started or peak was reset
55# TYPE jvm_threads_peak_threads gauge
56jvm_threads_peak_threads 32.0
57# HELP process_uptime_seconds The uptime of the Java virtual machine
58# TYPE process_uptime_seconds gauge
59process_uptime_seconds 13.385
60# HELP process_cpu_usage The "recent cpu usage" for the Java Virtual Machine process
61# TYPE process_cpu_usage gauge
62process_cpu_usage 0.0
63# HELP jvm_memory_max_bytes The maximum amount of memory in bytes that can be used for memory management
64# TYPE jvm_memory_max_bytes gauge
65jvm_memory_max_bytes{area="heap",id="G1 Survivor Space",} -1.0
66jvm_memory_max_bytes{area="heap",id="G1 Old Gen",} 4.294967296E9
67jvm_memory_max_bytes{area="nonheap",id="Metaspace",} -1.0
68jvm_memory_max_bytes{area="nonheap",id="CodeHeap 'non-nmethods'",} 7553024.0
69jvm_memory_max_bytes{area="heap",id="G1 Eden Space",} -1.0
70jvm_memory_max_bytes{area="nonheap",id="Compressed Class Space",} 1.073741824E9
71jvm_memory_max_bytes{area="nonheap",id="CodeHeap 'non-profiled nmethods'",} 2.44105216E8
72# HELP logback_events_total Number of error level events that made it to the logs
73# TYPE logback_events_total counter
74logback_events_total{level="warn",} 0.0
75logback_events_total{level="debug",} 0.0
76logback_events_total{level="error",} 0.0
77logback_events_total{level="trace",} 0.0
78logback_events_total{level="info",} 8.0
79# HELP system_load_average_1m The sum of the number of runnable entities queued to available processors and the number of runnable entities running on the available processors averaged over a period of time
80# TYPE system_load_average_1m gauge
81system_load_average_1m 3.18994140625
82# HELP jvm_gc_memory_promoted_bytes_total Count of positive increases in the size of the old generation memory pool before GC to after GC
83# TYPE jvm_gc_memory_promoted_bytes_total counter
84jvm_gc_memory_promoted_bytes_total 0.0
85# HELP jvm_threads_states_threads The current number of threads having NEW state
86# TYPE jvm_threads_states_threads gauge
87jvm_threads_states_threads{state="runnable",} 14.0
88jvm_threads_states_threads{state="blocked",} 0.0
89jvm_threads_states_threads{state="waiting",} 11.0
90jvm_threads_states_threads{state="timed-waiting",} 5.0
91jvm_threads_states_threads{state="new",} 0.0
92jvm_threads_states_threads{state="terminated",} 0.0
93# HELP jvm_memory_committed_bytes The amount of memory in bytes that is committed for the Java virtual machine to use
94# TYPE jvm_memory_committed_bytes gauge
95jvm_memory_committed_bytes{area="heap",id="G1 Survivor Space",} 1.048576E7
96jvm_memory_committed_bytes{area="heap",id="G1 Old Gen",} 1.31072E8
97jvm_memory_committed_bytes{area="nonheap",id="Metaspace",} 4.1336832E7
98jvm_memory_committed_bytes{area="nonheap",id="CodeHeap 'non-nmethods'",} 2949120.0
99jvm_memory_committed_bytes{area="heap",id="G1 Eden Space",} 1.26877696E8
100jvm_memory_committed_bytes{area="nonheap",id="Compressed Class Space",} 5767168.0
101jvm_memory_committed_bytes{area="nonheap",id="CodeHeap 'non-profiled nmethods'",} 7012352.0
102# HELP tomcat_sessions_active_max_sessions
103# TYPE tomcat_sessions_active_max_sessions gauge
104tomcat_sessions_active_max_sessions 0.0
105# HELP jvm_buffer_memory_used_bytes An estimate of the memory that the Java virtual machine is using for this buffer pool
106# TYPE jvm_buffer_memory_used_bytes gauge
107jvm_buffer_memory_used_bytes{id="mapped",} 0.0
108jvm_buffer_memory_used_bytes{id="direct",} 24576.0
109# HELP jvm_gc_memory_allocated_bytes_total Incremented for an increase in the size of the young generation memory pool after one GC to before the next
110# TYPE jvm_gc_memory_allocated_bytes_total counter
111jvm_gc_memory_allocated_bytes_total 2.7262976E7
112# HELP jvm_classes_loaded_classes The number of classes that are currently loaded in the Java virtual machine
113# TYPE jvm_classes_loaded_classes gauge
114jvm_classes_loaded_classes 7336.0
115# HELP jvm_classes_unloaded_classes_total The total number of classes unloaded since the Java virtual machine has started execution
116# TYPE jvm_classes_unloaded_classes_total counter
117jvm_classes_unloaded_classes_total 0.0
118# HELP tomcat_sessions_created_sessions_total
119# TYPE tomcat_sessions_created_sessions_total counter
120tomcat_sessions_created_sessions_total 0.0
121# HELP process_files_max_files The maximum file descriptor count
122# TYPE process_files_max_files gauge
123process_files_max_files 10240.0
124# HELP tomcat_sessions_alive_max_seconds
125# TYPE tomcat_sessions_alive_max_seconds gauge
126tomcat_sessions_alive_max_seconds 0.0
127# HELP jvm_buffer_total_capacity_bytes An estimate of the total capacity of the buffers in this pool
128# TYPE jvm_buffer_total_capacity_bytes gauge
129jvm_buffer_total_capacity_bytes{id="mapped",} 0.0
130jvm_buffer_total_capacity_bytes{id="direct",} 24576.0
131# HELP system_cpu_count The number of processors available to the Java virtual machine
132# TYPE system_cpu_count gauge
133system_cpu_count 12.0
134# HELP jvm_threads_live_threads The current number of live threads including both daemon and non-daemon threads
135# TYPE jvm_threads_live_threads gauge
136jvm_threads_live_threads 30.0
137# HELP process_start_time_seconds Start time of the process since unix epoch.
138# TYPE process_start_time_seconds gauge
139process_start_time_seconds 1.603358363515E9
140# HELP tomcat_sessions_expired_sessions_total
141# TYPE tomcat_sessions_expired_sessions_total counter
142tomcat_sessions_expired_sessions_total 0.0
143# HELP jvm_threads_daemon_threads The current number of live daemon threads
144# TYPE jvm_threads_daemon_threads gauge
145jvm_threads_daemon_threads 26.0

Custom Metrics

We can also define some custom metrics, which I will demonstrate in this section. The demo contains a Scheduler class which periodically runs the included schedulingTask method.

To be able to send custom metrics we need to import MeterRegistry from the Micrometer library and inject it into our class. For more detail please check the official documentation.

It is possible to instantiate these types of meters from MeterRegistry:

  • Counter: reports merely a count over a specified property of an application
  • Gauge: shows the current value of a meter
  • Timers: measures latencies or frequency of events
  • DistributionSummary: provides distribution of events and a simple summary

I implemented a counter and a gauge for demonstration purposes:

1@Component
2public class Scheduler {
3
4  private final AtomicInteger testGauge;
5  private final Counter testCounter;
6
7  public Scheduler(MeterRegistry meterRegistry) {
8    // Counter vs. gauge, summary vs. histogram
9    // https://prometheus.io/docs/practices/instrumentation/#counter-vs-gauge-summary-vs-histogram
10    testGauge = meterRegistry.gauge("custom_gauge", new AtomicInteger(0));
11    testCounter = meterRegistry.counter("custom_counter");
12  }
13
14  @Scheduled(fixedRateString = "1000", initialDelayString = "0")
15  public void schedulingTask() {
16    testGauge.set(Scheduler.getRandomNumberInRange(0, 100));
17
18    testCounter.increment();
19  }
20
21  private static int getRandomNumberInRange(int min, int max) {
22    if (min >= max) {
23      throw new IllegalArgumentException("max must be greater than min");
24    }
25
26    Random r = new Random();
27    return r.nextInt((max - min) + 1) + min;
28  }
29}

If we run the application we can see that our custom metrics are exposed via the actuatuor/prometheus endpoint:

bash
1 http GET "http://localhost:8080/actuator/prometheus" | grep custom
2# HELP custom_gauge
3# TYPE custom_gauge gauge
4custom_gauge 29.0
5# HELP custom_counter_total
6# TYPE custom_counter_total counter
7custom_counter_total 722.0

As we now have the metrics available in a format that Prometheus can understand, we will look at how to set up Prometheus.

Prometheus

Prometheus stores our metric data in time series in memory by periodically pulling it via HTTP. The data can be visualized by a console template language, a built-in expression browser, or by integrating Grafana (which we will do after setting up Prometheus).

In this demo, we will run Prometheus locally in a Docker container and we, therefore, need some configurations in a prometheus.yml file that you can place anywhere on your hard drive:

yaml
1global:
2  scrape_interval: 10s # How frequently to scrape targets by default
3
4scrape_configs:
5  - job_name: 'spring_micrometer' # The job name is assigned to scraped metrics by default.
6    metrics_path: '/actuator/prometheus' # The HTTP resource path on which to fetch metrics from targets.
7    scrape_interval: 5s # How frequently to scrape targets from this job.
8    static_configs: # A static_config allows specifying a list of targets and a common label set for them
9      - targets: ['192.168.178.22:8080']

All available configuration options can be seen in the official documentation.

As we want to run Prometheus in a Docker container we need to tell Prometheus our IP address instead of localhost in static_configs -> targets. Instead of localhost:8080 we are using 192.168.178.22:8080 where 192.168.178.22 is my IP address at the moment. To get your system IP you can use ifconfig or ipconfig in your terminal depending on your operating system.

Now we are ready to run Prometheus:

bash
docker run -d -p 9090:9090 -v <path-to-your-prometheus.yml>:/etc/prometheus/prometheus.yml prom/prometheus

<path-to-your-prometheus.yml> should be the path where you placed the prometheus.yml configuration file described above.

Finally, we can open the Prometheus on http://localhost:9090 in the web browser and search for our custom metric named custom_gauge:

Prometheus Graph

To check that Prometheus is correctly listening to our locally running Spring Boot application we can navigate to Status -> Targets in the top main navigation bar:

Prometheus Targets

Prometheus provides a query language PromQL, check the official documentation for more details.

Grafana

The included Prometheus browser graph is nice for basic visualization of our metrics but we will use Grafana instead. Grafana provides a rich UI where you create, explore and share dashboards that contain multiple graphs.

Grafana can pull data from various data sources like Prometheus, Elasticsearch, InfluxDB, etc. It also allows you to set rule-based alerts, which then can notify you over Slack, Email, Hipchat, and similar.

We start Grafana also locally in a Docker container:

bash
docker run -d -p 3000:3000 grafana/grafana

Opening http://localhost:3000 in a browser should now show the following login page:

Grafana Login

You can log in using the default username admin and the default password admin. After login, you should change these default passwords by visiting http://localhost:3000/profile/password.

The first step is to add our local Prometheus as our data source:

Grafana Add DatasourceGrafana Select PrometheusGrafana Prometheus Config

Community Dashboard

The first dashboard we want to add is a community dashboard. As we are using a Spring Boot application we choose the popular JVM dashboard:

Grafana Import JVM Dashboard

After loading the URL we can see the imported dashboard:

Grafana Imported JVM Dashboard

Custom Metric Dashboard

Finally, we want to create a new dashboard where we show our custom metrics. The first step is to create a new dashboard:

Grafana Imported JVM Dashboard

Now we see a new dashboard where we can create a new panel:

Grafana New Dashboard Panel

In the first panel we add a visualization for our custom_gauge metric. I use the Stat visualization as it shows the current value and a simple graph:

Grafana Stat Gauge Vizualization

Additionally, a new panel for the custom_counter metric is added to our dashboard:

Grafana Graph Counter Vizualization

In the end, the dashboard looks like this:

Grafana Custom Dashboard

Conclusion

It is important to monitor an application's metrics and health which helps us to improve performance, manage the app in a better way and notice unoptimized behavior. Monitoring each service is important to be able to maintain a system that consists of many microservices.

In this article, I showed how a Spring Boot web application can be monitored using Micrometer which exposes metrics from our application, Prometheus which stores the metric data and Grafana to visualize the data in graphs.

This popular monitoring approach should help you to maintain your applications and make your customers happy.

As always, the code for the demo used in this article can be found on GitHub.

I will never share any of your personal data. You can unsubscribe at any time.

If you found this article helpful.You will love these ones as well.
How To Generate Angular & Spring Code From OpenAPI Specification Image

How To Generate Angular & Spring Code From OpenAPI Specification

Sending Message To Specific Anonymous User On Spring WebSocket Image

Sending Message To Specific Anonymous User On Spring WebSocket

JHipster - The Fastest Way To Build A Production-Ready Angular & Spring Boot Application Image

JHipster - The Fastest Way To Build A Production-Ready Angular & Spring Boot Application

How I Replaced Revue With a Custom-Built Newsletter Service Using Nuxt 3, Supabase, Serverless, and Amazon SES Image

How I Replaced Revue With a Custom-Built Newsletter Service Using Nuxt 3, Supabase, Serverless, and Amazon SES
